Aluminum alloy is a lightweight, high-strength material widely used in aerospace, automotive, electrical, chemical, and other industries. It has excellent corrosion resistance, thermal conductivity, and mechanical properties. However, aluminum alloys also face several welding challenges, such as the formation of an oxide film, hot cracking, deformation, and increased stress, which can affect the quality and reliability of welded joints. Therefore, understanding the welding characteristics of aluminum alloys and mastering the correct welding methods and techniques are essential to ensure the success of aluminum alloy welding projects.
This article will introduce the welding characteristics of aluminum alloys from the following aspects:
Oxidation: Aluminum and its alloys easily oxidize in air and during welding, forming a refractory oxide film.
Expansion and Contraction: Aluminum and its alloys have a high coefficient of linear expansion and crystallization shrinkage, leading to significant welding deformation and internal stress.
Reflection and Color Change: Aluminum and its alloys have a strong ability to reflect light and heat, with no noticeable color change during the solid-liquid transition.
Hydrogen Solubility: Aluminum and its alloys can dissolve a large amount of hydrogen in the liquid state and almost none in the solid state. They can also dissolve a large amount of water in the liquid state and almost none in the solid state.
Alloy Element Evaporation: Alloy elements easily evaporate and burn off, degrading the performance of the weld.
Heat-Affected Zone: If the base metal is work-hardened or age-hardened, welding heat will reduce the strength of the heat-affected zone.
No Phase Transformation: Aluminum has a face-centered cubic lattice with no allotropes, so there are no phase changes during heating and cooling.
Based on the above analysis, we can choose appropriate welding methods for aluminum and its alloys. Currently, the commonly used welding methods for aluminum and its alloys include:
Gas Welding: Uses a high-temperature flame produced by mixing combustible gas with air or inert gas to locally heat and fill the joint between two workpieces with filler material (such as welding rods). Gas welding equipment is simple, easy to operate, and low-cost, suitable for repairing or connecting aluminum and its alloys where quality requirements are not high or in large quantities.
Shielded Metal Arc Welding (SMAW)： Uses an electric arc generated between the electrode and the workpiece to locally heat and fill the joint with filler material (such as flux-cored wire).SMAW equipment is flexible and varied, requiring high technical skills, and is suitable for high-quality or small-quantity welding of aluminum and its alloys with complex shapes, large thicknesses, or special requirements for preheating or post-heating.
Gas Tungsten Arc Welding (GTAW): Uses an inert gas to protect the stable arc between the electrode and the workpiece, locally heating and filling the joint with filler material (such as flux-cored wire). GTAW equipment is precise and reliable, requiring high technical skills, and is one of the most commonly used methods for welding aluminum and its alloys. GTAW can be divided into manual and automatic types; the former is suitable for high-quality requirements, small-quantity, complex shapes, or thin-walled aluminum and its alloys, while the latter is suitable for lower-quality requirements, large-quantity, simple shapes, or thick-walled aluminum and its alloys.
Laser Welding: Uses a high-energy laser beam to locally heat and fill the joint with filler material (such as flux-cored wire). Laser welding equipment is efficient and energy-saving, requiring high technical skills, and is a new method for welding aluminum and its alloys. Laser welding can be divided into continuous and pulsed types; the former is suitable for extremely high-quality requirements, very small quantities, extremely complex shapes, or very thin aluminum and its alloys, while the latter is suitable for high-quality requirements, small-quantity, complex shapes, or thin aluminum and its alloys.
Friction Welding: Uses the friction heat generated by the relative motion between two workpieces to locally heat and fill the joint with filler material (such as flux-cored wire). Friction welding equipment is simple and easy to use, requiring low technical skills, and is suitable for the mass production of aluminum and its alloys. Friction welding can be divided into direct and indirect types; the former is suitable for low-quality requirements, large-quantity, simple shapes, or thick aluminum and its alloys, while the latter is suitable for high-quality requirements, small-quantity, complex shapes, or thin aluminum and its alloys.
Aluminum alloy is an excellent lightweight, high-strength material, but its welding performance is poor and requires appropriate welding methods and techniques to ensure the quality and reliability of welded joints. This article has introduced the welding characteristics of aluminum and its alloys, including oxide film formation, hot cracking, deformation stress, hydrogen pores, alloy element burn-off, strength reduction in the heat-affected zone, and the absence of phase transformation. Based on these characteristics, the advantages, disadvantages, and applications of gas welding, shielded metal arc welding, gas tungsten arc welding, laser welding, and friction welding have been analyzed. It is hoped that this article can provide some reference and guidance for welding projects involving aluminum and its alloys.
